World RRP: £149.95
Category: Midbass & Midrange Speakers
Product code: TeamSQ6/4
Product Category | Midbass & Midrange Speakers |
Version | 1 |
Series | Team |
First Added | 13/09/2021 |
Last Modified | 14/12/2023 |
Barcode | 5060905110384 |
Production Status | Current |
Product Net Weight (g) (For Pairs/Sets/Major Parts) | 1200 |
Product Height (mm) | 73 |
Product Length (mm) | 165 |
Product Width (mm) | 165 |
Complete Product Pack Weight (g) | 1500 |
Operating Temperature (Degrees Celsius) | 0-50 |
Warranty (Months) - Private Enjoyment Use Only | 12 |
Sold As | Single |
Continuous RMS Power (Watts) (One Speaker, Using Appropriate Crossover & 0%THD) | 75 |
Overall Diameter (mm) | 165 |
Magnet Diameter (mm) (Including Magnet Protector Where Applicable) | 100 |
Installation Cut-Out Diameter (mm) | 156 |
Overall Depth (mm) | 71 |
Mounting Depth (mm) | 66 |
Front Protrusion From Mounting Plane (mm) | 5 |
System Frequency Response (Hz) | 60>5000 |
Impedance (Ohm) (Nominal) | 4 |
Sensitivity (db/1Wm) | 91 |
Total Magnet Weight (Oz) | 15 |
Magnet Size (mm) | 22x10 (x10) |
Magnet Type | N38 |
Magnet Qty | 10 |
Top Plate thickness (mm) | 6 |
Back Plate Thickness (mm) | 10 |
Voice Coil Former Spec | Kapton |
Voice Coil Type | CCA Round Wire |
Voice Coil External Diameter (mm) | 38.8 |
Voice Coil Internal Diameter (mm) | 38.6 |
Voice Coil Winding Height (mm) | 12 |
Voice Coil Winding (Layers) | 2 |
Cone Type | Kevlar |
Spider Compliance | Very Soft |
Spider Type | Nomex |
Spider Diameter (mm) | 103 |
Spider Design | Double |
Surround | Single Roll |
Surround Material | Rubber |
Tinsel Wire | Single |
Terminal | Screw type |
Xmax Single Way Total (mm) | 4.5 |
