World RRP: £77.95
Category: Coaxial & Component Speakers
Product code: IndyCX69
Product Category | Coaxial & Component Speakers |
Version | 1 |
Series | Indy |
First Added | 29/03/2021 |
Last Modified | 14/12/2023 |
Barcode | 5060905110285 |
Production Status | Current |
Product Net Weight (g) (For Pairs/Sets/Major Parts) | 3000 |
Product Height (mm) | 68 |
Product Length (mm) | 235 |
Product Width (mm) | 163 |
Complete Product Pack Weight (g) | 3250 |
Operating Temperature (Degrees Celsius) | 0-50 |
Warranty (Months) - Private Enjoyment Use Only | 12 |
Sold As | Pair |
Voice Coil Diameter (mm) | 20.4 |
Overall Depth (mm) | 25 |
Mounting Depth (mm) | 17 |
Front Protrusion From Mounting Plane (mm) | 8 |
Overall Diameter (mm) | 46 |
Magnet Diameter (mm) | 19.5 |
Installation Cut-out Diameter (mm) | 40 |
Magnet Weight (Oz) | 0.25 |
Magnet Type | NdFeB-N38 |
System RMS (Watts) (Single Tweeter, 4Khz/12DB Oct X Over) | 40 |
Frequency Response (Hz) | 1500>20000 |
Impedance (Ohm) | 4 |
Sensitivity (db/1Wm) | 92 |
Continuous RMS Power (Watts) (One Speaker, Using Appropriate Crossover & 0%THD) | 80 |
Impedance (Ohm) (Nominal) | 4 |
Sensitivity (db/1Wm) | 91 |
Total Magnet Weight (Oz) | 20 |
Optimum Bass Enclosure Type | IB |
Voice Coil Former Spec | Kapton |
Voice Coil Type | SV Type (200 Degree C) |
Voice Coil External Diameter (mm) | 25.7 |
Voice Coil Internal Diameter (mm) | 25.5 |
Voice Coil Winding Height (mm) | 9 |
Voice Coil Winding (Layers) | 2 |
Cone Type | Injection PP |
Spider Compliance | 0.5 |
Spider Type | Progressive |
Spider Diameter (mm) | 115 |
Spider Design | Single |
Surround | Rubber |
Surround Material | Rubber |
Tinsel Wire | High Temperature |
Terminal | Screw type |
Full System Power Handling RMS (Watts) (Using Pair/Full Set Of Speakers Not Necessarily Included & Appropriate Crossover) | 160 |
SPL (db/1Wm) | 91 |
