World RRP: £63.95
Category: Bass Tubes
Product code: GT-BASS10.1
Product Category | Bass Tubes |
Version | 1 |
Series | GT Audio |
First Added | 12/06/2023 |
Last Modified | 07/12/2023 |
Barcode | 5060905111268 |
Production Status | Current |
Product Net Weight (g) (For Pairs/Sets/Major Parts) | 5300 |
Product Height (mm) | 290 |
Product Length (mm) | 480 |
Product Width (mm) | 290 |
Complete Product Pack Weight (g) | 5900 |
Operating Temperature (Degrees Celsius) | 0-50 |
Weatherproof Rating | In-Car Only |
Warranty (Months) - Private Enjoyment Use Only | 12 |
Sold As | Single |
Speaker Maximum Burst Power (Watts) (One Speaker, Using Appropriate Crossover) | 1100 |
Speaker Power Handling RMS (Watts) (One Speaker, Using Appropriate Crossover) | 550 |
Continuous RMS Power (Watts) (One Speaker, Using Appropriate Crossover & 0%THD) | 420 |
Overall Diameter (mm) | 295 |
System Frequency Response (Hz) | 40-600 |
Recommended Frequency Range (Hz) | 50-300 |
Impedance (Ohm) (Nominal) | 4 |
Sensitivity (db/1Wm) | 86.39 |
Total Magnet Weight (Oz) | 24 |
Magnet Size (mm) | 100x20 |
Voice Coil Former Spec | Aluminum |
Voice Coil Type | Copper Round Wire |
Voice Coil External Diameter (mm) | 41.85 |
Voice Coil Internal Diameter (mm) | 38.6 |
Voice Coil Winding Height (mm) | 15 |
Voice Coil Winding (Layers) | 4 |
Cone Type | Non-Pressed Paper |
Spider Compliance | Medium |
Spider Type | Linear |
Spider Diameter (mm) | 125 |
Spider Design | Single |
Surround | Smooth |
Surround Material | Foam |
Tinsel Wire | Single |
Terminal | Push |
SPL (db/1Wm) | 86.39 |
Xmax Single Way Total (mm) | 4.5 |
